The Image Column Gallery displays images from space and page or custom selected images within a column layout.
Macro paramaters
| Label | Parameter | Default | Description | Hosting Type |
|---|---|---|---|---|
| Sources | sources | Current page | Specify the title of space or page which contains the images or image title you want displayed. You can specify more than one source in autocomplete field. | Server |
| Labels | labelsFilter | Filters the images to display, based on a list of labels. If you wish to enter more than one label, separate the labels with commas. | Server, Cloud | |
| Number | maxNumber | 200 | Maximum number of images. Admin can define global max limit for application. Value of global max limit will be used if default or custom value is highter. | Server, Cloud |
| Sort Images By | sort | name | Specify an attribute to sort the images by. Sort order is ascending, unless you select the Reverse Sort parameter (see below). | Server |
| Sort | reverse | ascending | Used in combination with the Sort Images By parameter above. Use Reverse Sort to reverse the sort order, from ascending to descending. | Server |
| Size | itemSize | 200 | Size of image container in pixel. | Server, Cloud |
| Vertical gutter | gutterX | 15 | Size of vertical gutter in pixel. | Server, Cloud |
| Horizontal gutter | gutterY | 15 | Size of horizontal gutter in pixel. | Server, Cloud |
| Animate | animate | Yes | Image positioning will be animated, for instance when the page is resized. | Server, Cloud |
| Captions | captions | No | Image comment as caption. | Server |
With Animation
Resize the browser window to see the effect.
Without Animation
Filtered by label
No horizontal gutter
No vertical gutter
No gutter
Max number
Different image size
Images generated using: http://dummy-image-generator.com
